BluePeak Dual Tank system: a water softener tank, a separate catalytic carbon tank and a brine tank, cut away to show the media
City water

Dual Tank (Whole-Home Filter + Softener, two tanks)

Two tanks instead of one: a dedicated softening tank and a dedicated catalytic carbon tank, treating in stages. The upgrade over the Single Tank: when the carbon wears out, you replace only that tank, and both last longer. It is our most complete whole house water filtration system for city water.

up to 3 bathrooms or 7 people

Regular price$5,685Sale price$3,695

Installed

35% Off + Free RO Drinking System · ends November 30, 2026

Free tank-style Reverse Osmosis Drinking System included

Every price is the installed price. We confirm your price with you on the call, before any work begins.

Key specs

Best for
up to 3 bathrooms or 7 people
Water
City water
System
Softener + carbon, 2 tanks
Tanks
Two 10" × 60"
Capacity
48,000 grains + carbon tank
Flow
8–12 GPM (10" tanks)
Warranty
Valve moving parts covered as long as you own the home

Not sure? We size it to how your family actually uses water.

Tap to zoom

Direct downloads. No form, no email required.

Preview of the Dual Tank (Whole-Home Filter + Softener, two tanks) brochure

Full specifications

Key specifications

Best forup to 3 bathrooms or 7 people
WaterCity water
Softening capacity48,000 grains (resin tank)
ConfigurationTwo tanks — one resin, one carbon
Media tanks (D × H)10" × 60" each
Brine / salt tank15" × 35" square
Connections1" NPT elbows · 1.25" distributor tube
Bypass valve1" full-flow, included
BackflushBoth tanks, to extend system life
Service flow rate8–12 GPM (10" tanks)
Valve flow rate28 GPM

Operating requirements

Operating pressure30 – 125 PSI
Water temperature40° – 110°F (4° – 43°C)
Electrical120V / 60Hz — 12V 650mA transformer
Inlet turbidityUnder 5 FTU
Service flow8–12 GPM (10" tanks)
Backwash flow3.0 gal/min
RegenerationUpflow counter-current, demand-initiated metering

What the catalytic carbon reduces

  • Chlorine and chloramines
  • THMs & byproducts
  • VOCs
  • Pesticides and herbicides
  • Hydrogen sulfide odor
  • Taste and odor
  • Hardness (via resin)

Components and warranty

Control valveBluePeak ProValve — Hankscraft ceramic disc, assembled in Wisconsin, 72-hour memory backup
Mineral tankTwo Enpress fiberglass pressure tanks — made in Ohio · NSF-certified polishing gravel support beds
Softening resinResinTech CG10 strong-acid cation, 10% crosslinked — New Jersey, WQA Gold Seal
Carbon mediaJacobi AquaSorb CX-MCA catalytic coconut-shell carbon — steam-activated, NSF/ANSI 61 & 42
Carbon gradeCatalytic (chloramine + H₂S); iodine ≥1,000 mg/g; 1,050 m²/g surface area
AssemblyAssembled in Texas
CertificationsCertified to NSF/ANSI 42, 44 and 61
WarrantyValve moving parts for as long as you own the home · electronics 5 years · media, RO and install 1 year · tanks per manufacturer
InstallationIncluded — by a licensed North Carolina plumber
Drinking waterFree reverse osmosis drinking system included, installed at the kitchen sink

Real installs

This system, installed by BluePeak in Triangle homes. Select a photo to enlarge it.

  • BluePeak Dual Tank system in a Durham garage: two black media tanks and a brine tank beside the garage steps
    Dual Tank · Durham

See the full install gallery ›

What it does

Water passes through two 10 x 60 inch tanks, one after the other. One holds ResinTech CG10 softening resin, rated at 48,000 grains, and takes out the calcium and magnesium behind scale and spotting. The other is a dedicated bed of Jacobi catalytic coconut-shell carbon for chlorine, chloramine, taste and smell.

Softening does not clean your water and filtering does not soften it. They are two different jobs, and here each one gets a full tank of its own media instead of sharing a bed. Both tanks backflush to extend the life of the system, on a BluePeak ProValve ceramic disc valve.

Who it is for

Any city home that wants the upgrade over the Single Tank: each media gets a full tank of its own, the carbon can be replaced on its own when it wears out, and both tanks last longer for it.

Size is a separate question: it decides between the Single Tank (up to 3 bathrooms or 6 people) and the Single Tank XL (4 or more bathrooms, or 8 or more people), not whether you need two tanks. Not sure? We size it to how your family actually uses water. If you are on a well rather than city water, the well water systems are a different build and a better fit.

Questions about this system

Single tank or dual tank — how do I know?

It comes down to how much water you use and what is in it. Our Single Tank puts softening resin and catalytic carbon together in one mixed bed, which suits city homes with up to 3 bathrooms or 6 people, and the Single Tank XL is the same build in a larger tank for 4 or more bathrooms or 8 or more people. A dual tank gives each media its own tank: a softener tank plus a catalytic carbon tank on city water, or on a well, a softener tank plus an iron and sulfur tank. On city water the Dual Tank is the upgrade rather than a size: when the carbon wears out you replace only that tank, and both last longer. Size decides between the Single Tank and the XL. We size it off your test and your household. Not sure? We size it to how your family actually uses water.

What’s the difference between a water softener and a water filter?

Different jobs. A softener uses resin and salt to remove calcium and magnesium — the minerals that cause scale, spotting and that film on your skin. A filter uses carbon or specialty media to remove chlorine, taste, odor and other contaminants. Softening doesn’t clean your water; filtering doesn’t soften it. Most Triangle city homes need filtering more than softening. Well homes often need both, plus more.

How much salt will I use?

For a typical Triangle household on a properly sized softener, figure on a bag every two to three months. It depends on your hardness level and how much water you use. If you’re going through salt much faster than that, something is set wrong.

Will this hurt my water pressure?

A properly sized system, no. An undersized one, yes — which is the most common installation mistake in this industry. Our systems are sized on service flow rate against your household’s peak demand: 8–12 GPM from a 10-inch tank, 12–14 GPM from a 12-inch tank. If someone quotes you a system without asking how many people live in your home, that’s a red flag.
