BluePeak Single Tank XL system: one larger tank of softener resin and catalytic carbon beside its brine tank

Shown: Standard size

City water

Single Tank XL (Whole-Home Filter + Softener, one tank)

The larger mixed-bed tank, for homes with 4 or more bathrooms or 8 or more people. Same resin, same catalytic carbon, a third more capacity between regenerations.

4+ bathrooms or 8+ people

Regular price$4,538Sale price$2,950

Installed

35% Off + Free RO Drinking System · ends November 30, 2026

Free tank-style Reverse Osmosis Drinking System included

Every price is the installed price. We confirm your price with you on the call, before any work begins.

Key specs

Best for
4+ bathrooms or 8+ people
Water
City water
System
Softener + carbon
Tank
12" × 58" mixed bed
Capacity
48,000 grains
Flow
12–14 GPM (12" tank)
Warranty
Valve moving parts covered as long as you own the home

Not sure? We size it to how your family actually uses water.

Tap to zoom

Direct downloads. No form, no email required.

Preview of the Single Tank XL (Whole-Home Filter + Softener, one tank) brochurePreview of the Single Tank XL (Whole-Home Filter + Softener, one tank) brochure

Full specifications

Key specifications

Best for4+ bathrooms or 8+ people
WaterCity water
Softening capacity48,000 grains
Media tank (D × H)12" × 58"
Media volume1.5 cu ft resin + carbon
Brine / salt tank15" × 35" square
Connections1" NPT elbows · 1.25" distributor tube
Bypass valve1" full-flow, included
Service flow rate12–14 GPM (12" tank)
Valve flow rate28 GPM

Operating requirements

Operating pressure30 – 125 PSI
Water temperature40° – 110°F (4° – 43°C)
Electrical120V / 60Hz — 12V 650mA transformer
Inlet turbidityUnder 5 FTU
Service flow12–14 GPM (12" tank)
Backwash flow3.0 gal/min
RegenerationUpflow counter-current, demand-initiated metering

What the catalytic carbon reduces

  • Chlorine and chloramines
  • THMs & byproducts
  • VOCs
  • Pesticides and herbicides
  • Hydrogen sulfide odor
  • Taste and odor
  • Hardness (via resin)

Components and warranty

Control valveBluePeak ProValve — Hankscraft ceramic disc, assembled in Wisconsin, 72-hour memory backup
Mineral tankEnpress fiberglass pressure tank — made in Ohio · NSF-certified polishing gravel support bed
Softening resinResinTech CG10 strong-acid cation, 10% crosslinked — New Jersey, WQA Gold Seal
Carbon mediaJacobi AquaSorb CX-MCA catalytic coconut-shell carbon — steam-activated, NSF/ANSI 61 & 42
Carbon gradeCatalytic (chloramine + H₂S); iodine ≥1,000 mg/g; 1,050 m²/g surface area
AssemblyAssembled in Texas
CertificationsCertified to NSF/ANSI 42, 44 and 61
WarrantyValve moving parts for as long as you own the home · electronics 5 years · media, RO and install 1 year · tanks per manufacturer
InstallationIncluded — by a licensed North Carolina plumber
Drinking waterFree reverse osmosis drinking system included, installed at the kitchen sink

Real installs

This system, installed by BluePeak in Triangle homes. Select a photo to enlarge it.

  • BluePeak Single Tank XL with its brine tank and wall-mounted plumbing loop in a Cary garage
    Single Tank XL · Cary

See the full install gallery ›

What it does

Same job as the standard Single Tank, sized up. A 12 x 58 inch tank holds a 1.5 cubic foot mixed bed of ResinTech CG10 softening resin and Jacobi catalytic coconut-shell carbon, rated at 48,000 grains. It softens and it filters: hardness, chlorine, chloramine, taste and smell, across the whole house.

The difference is capacity. A bigger bed goes longer between regenerations, which is what a busy household needs. Same BluePeak ProValve, same media and the same certifications as the standard tank. An undersized system is the most common installation mistake in this industry, and this is the tank that avoids it in a large home.

Who it is for

Larger homes on city water: 4 or more bathrooms, or 8 or more people. A standard tank would be working at its limit in a house like that. It goes in the garage or at an accessible main water line, on a 28 GPM valve. Not sure? We size it to how your family actually uses water.

Below that, buy the standard Single Tank instead. Same media, same valve, lower price. The XL earns the difference only when the demand is genuinely there. The upgrade over either size is the Dual Tank: softener and carbon in separate tanks, so when the carbon wears out you replace only that tank.

Questions about this system

What if I have a big household?

Standard tanks get outrun by high-demand households. Our Single Tank XL is built for homes with 4 or more bathrooms, or 8 or more people: a larger 12 x 58 inch tank rated at 48,000 grains, a third more capacity than the standard Single Tank, with 12–14 GPM of service flow, so it keeps up at peak demand and goes longer between regenerations. Household size decides between the Single Tank and the XL. The Dual Tank is a different question, the upgrade rather than a size: softener and carbon in separate tanks, so you replace only the carbon tank when it wears out. Not sure? We size it to how your family actually uses water.

Will this hurt my water pressure?

A properly sized system, no. An undersized one, yes — which is the most common installation mistake in this industry. Our systems are sized on service flow rate against your household’s peak demand: 8–12 GPM from a 10-inch tank, 12–14 GPM from a 12-inch tank. If someone quotes you a system without asking how many people live in your home, that’s a red flag.

Single tank or dual tank — how do I know?

It comes down to how much water you use and what is in it. Our Single Tank puts softening resin and catalytic carbon together in one mixed bed, which suits city homes with up to 3 bathrooms or 6 people, and the Single Tank XL is the same build in a larger tank for 4 or more bathrooms or 8 or more people. A dual tank gives each media its own tank: a softener tank plus a catalytic carbon tank on city water, or on a well, a softener tank plus an iron and sulfur tank. On city water the Dual Tank is the upgrade rather than a size: when the carbon wears out you replace only that tank, and both last longer. Size decides between the Single Tank and the XL. We size it off your test and your household. Not sure? We size it to how your family actually uses water.

What maintenance does the system need?

Drinking water (RO) filters: about once a year. RO membrane: every 2 years. Salt: check monthly, top up as needed. UV bulb: every year. Pre-sediment cartridge: every 6 months.
